VBMT160408-TF P2125
Turning insert
500-00797
Technical Diagram
Product Details
| Item Number | Designation |
RE (mm)
Corner radius
|
L1 (mm)
Insert edge length
|
IC (mm)
Insert size
|
S (mm)
Insert thickness
|
D1 (mm)
Hole diameter
|
Min. ap (mm)
Minimum depth of cut
|
Max. ap (mm)
maximum depth of cut
|
Min. ft (mm/rev)
Minimum feedrate
|
Max. ft (mm/rev)
Maximum feed rate
|
Q
Grade
|
|---|---|---|---|---|---|---|---|---|---|---|---|
| 500-00797 | VBMT160408-TF P2125 | 0.8 | 16.5 | 9.52 | 4.76 | 4.4 | 0.40 | 1.50 | 0.05 | 0.25 | P2125 |
Designation
VBMT160408-TF P2125
RE (mm)
Corner radius
0.8
L1 (mm)
Insert edge length
16.5
IC (mm)
Insert size
9.52
S (mm)
Insert thickness
4.76
D1 (mm)
Hole diameter
4.4
Min. ap (mm)
Minimum depth of cut
0.40
Max. ap (mm)
maximum depth of cut
1.50
Min. ft (mm/rev)
Minimum feedrate
0.05
Max. ft (mm/rev)
Maximum feed rate
0.25
Q
Grade
P2125
| GTIN(EAN) |
|---|
3D Model
2D Drawing
