CNMG190616-BR P2125
Turning insert
500-00717
Technical Diagram
Product Details
| Item Number | Designation |
RE (mm)
Corner radius
|
L1 (mm)
Insert edge length
|
IC (mm)
Insert size
|
S (mm)
Insert thickness
|
D1 (mm)
Hole diameter
|
Min. ap (mm)
Minimum depth of cut
|
Max. ap (mm)
maximum depth of cut
|
Min. ft (mm/rev)
Minimum feedrate
|
Max. ft (mm/rev)
Maximum feed rate
|
Q
Grade
|
|---|---|---|---|---|---|---|---|---|---|---|---|
| 500-00717 | CNMG190616-BR P2125 | 1.6 | 19.3 | 19.05 | 6.35 | 6.35 | 2.0 | 6.5 | 0.25 | 0.55 | P2125 |
Designation
CNMG190616-BR P2125
RE (mm)
Corner radius
1.6
L1 (mm)
Insert edge length
19.3
IC (mm)
Insert size
19.05
S (mm)
Insert thickness
6.35
D1 (mm)
Hole diameter
6.35
Min. ap (mm)
Minimum depth of cut
2.0
Max. ap (mm)
maximum depth of cut
6.5
Min. ft (mm/rev)
Minimum feedrate
0.25
Max. ft (mm/rev)
Maximum feed rate
0.55
Q
Grade
P2125
| GTIN(EAN) |
|---|
3D Model
2D Drawing
