CNMG120412-BF P2225
Turning insert
500-00552
Technical Diagram
Product Details
| Item Number | Designation |
RE (mm)
Corner radius
|
L1 (mm)
Insert edge length
|
IC (mm)
Insert size
|
S (mm)
Insert thickness
|
D1 (mm)
Hole diameter
|
Min. ap (mm)
Minimum depth of cut
|
Max. ap (mm)
maximum depth of cut
|
Min. ft (mm/rev)
Minimum feedrate
|
Max. ft (mm/rev)
Maximum feed rate
|
Q
Grade
|
|---|---|---|---|---|---|---|---|---|---|---|---|
| 500-00552 | CNMG120412-BF P2225 | 1.2 | 12.9 | 12.7 | 4.76 | 5.16 | 0.5 | 2.0 | 0.08 | 0.20 | P2225 |
Designation
CNMG120412-BF P2225
RE (mm)
Corner radius
1.2
L1 (mm)
Insert edge length
12.9
IC (mm)
Insert size
12.7
S (mm)
Insert thickness
4.76
D1 (mm)
Hole diameter
5.16
Min. ap (mm)
Minimum depth of cut
0.5
Max. ap (mm)
maximum depth of cut
2.0
Min. ft (mm/rev)
Minimum feedrate
0.08
Max. ft (mm/rev)
Maximum feed rate
0.20
Q
Grade
P2225
| GTIN(EAN) |
|---|
3D Model
2D Drawing
